| Optical system | Double beam |
| Wavelength range | 190 nm ~ 1100 nm |
| Spectral bandwidth | 0.5 nm, 1 nm, 2 nm, 5 nm |
| Stray light | ≤ 0.04 T at 360 nm; 220 nm |
| Wavelength accuracy | ± 0.3 nm |
| Wavelength repeatability | ≤ 0.2 nm |
| Photometric accuracy | ± 0.002 A (0 Abs ~ 0.5 Abs)
± 0.004 A (0.5 Abs ~ 1.0 Abs)
± 0.3% T (0% T ~ 100% T) |
| Photometric repeatability | 0.001 Abs (0 Abs ~ 0.5 Abs)
0.002 Abs (0.5 Abs ~ 1.0 Abs)
≤ 0.2% T (0% T ~ 100% T) |
| Stability | ± 0.0003 A/h at 500 nm |
| Baseline flatness | ± 0.0005 A |
| Noise | ± 0.0002 Abs |
| Display | 7 inch TFT LCD |
| Light source | Deuterium lamp, Tungsten lamp |
| Input | Membrane keypad |
| Output | USB print and data output |
| Power | AC 110V ± 10 %; 50 Hz
AC 220 V ±10% ; 60 Hz |
| Dimensions | 740 × 570 × 440 mm |
| Gross weight | 25 kg |
Photometric detection by fixed wavelength
Three modal standard curve
Wide scanning range for derivative and arithmetic operation, graphically
Multi-Wavelength configuration for measurement of transmittance and absorbance
Socket-type deuterium and tungsten lamps
Testing and storage capacity of 240 data in each curve
Automatic wavelength calibration, lamp source deviation and dark current calibration
Efficient time course scanning and reaction rate calculations
| Sr. No. | Name of the accessory |
|---|
| 1 | Single cell holder |
| 2 | General cell holder |
| 3 | Test tube holder |
| 4 | Solid sample holder |
| 5 | Deuterium lamp |
| 6 | Halogen lamp |
| 7 | 4 place cell holder |
| 8 | Printer |
| 9 | Water- jacketed cell holder ( 4 cells capacity ) |
| 10 | Constant temperature system |
| Sr. No. | Name of the accessory | Quantity |
|---|
| 1 | 10 mm glass cuvette | 4 units |
| 2. | 10 mm quartz cuvette | 2 units |
| 3. | Software | - |
